Economic Type Door Shrink Packing Machine: A Cost-Effective Packaging Solution

The economic type door shrink packing machine offers a highly efficient solution for packaging doors, providing a seamless combination of film application and heat shrinking technology. Designed to accommodate various door sizes, this machine ensures a smooth and tight package, enhancing both product protection and appearance.


Key Features of the Machine

The door shrink packing machine comprises multiple components, including conveyors, a film bagging mechanism, and a heat shrink tunnel. These components work together to ensure a high-quality, professional finish. Here's a step-by-step overview of how the process works:

Film Application and Sealing:

1.The door panel is initially covered with a plastic film using the film applicator.
2.The machine then uses a heat blade to cut and seal the film edges, creating a fully enclosed package.
Heat Shrinking:

1.Once sealed, the package is transferred to the shrink tunnel, where hot air is applied to shrink the film snugly around the door.
2.As the door exits the tunnel, two vertical press rollers smooth the film edges, ensuring a neat, professional appearance.
This system delivers a secure and visually appealing package, which adds value to manufacturers seeking to enhance their product presentation.



Economic Type Door Shrink Packing Machin

Shrinking Tunnel Features

  • Temperature Control: The tunnel operates between 100°C and 220°C, with precise temperature regulation to ensure optimal shrink wrapping.
  • Energy Efficiency:The insulation and recirculation system minimize heat loss, reducing energy consumption during operation.
  • Adjustable Conveyor Speed:The speed of the conveyor can be customized to match the requirements of the sealing and shrinking processes.

Advantages of the Automatic Shrink Sealing System

  • Automatic or Manual Modes: Users can select between automatic or manual feeding modes, depending on their production needs.
  • Custom Solutions: Provides a range of models and customizable options to suit various product sizes, shapes, and packaging requirements.
  • Adjustable Sealing Heights:The adjustable sealing height ensures compatibility with various door sizes.
  • Precise Operation:The photoelectric sensor ensures accurate positioning of the doors for wrapping, while a PLC-controlled system adjusts the sealing and shrink wrapping processes for maximum efficiency.
  • Error Prevention and Safety: The system features automatic error detection, helping to minimize downtime and ensure safe, smooth operation.


Economic Type Door Shrink Packing Machin

Technical Specifications

Max Door Width:
600mm-1250mm
Door Thickness Range:
20mm-60mm
Working Table Height:
800mm
Film Material:
PE shrink film with thickness options from 30 to 80 microns
Conveyor Speed:
Adjustable between 0-12 meters per minute
Power Consumption:
37kW for the shrinking process
Power Supply:
380V, 50/60Hz, 3-phase

Conclusion

The economic type door shrink packing machine offers an affordable yet highly effective solution for door manufacturers looking to streamline their packaging processes. With its automated features, adjustable settings, and robust construction, this machine is designed to improve packaging efficiency, reduce labor costs, and deliver high-quality, professionally packaged doors.
