Sleeve shrinking machine

SK-075C is an automatic packaging machine that is specifically designed for packaging products such as tapes, paper rolls, and cylindrical products. It is equipped with a heat blade for sealing and a shrink tunnel for shrinking the products. The machine is capable of collating and packing tapes in a tower or in a flat configuration, and it can be easily connected to a tape production line to impro

Free Consultation

Automatic sleeve shrinking machine SK-075C

Description
Other

Features:

1.SK-075C is a automatic machine which has heat blade for sealing and shrink tunnel for shrinking products, the machine is used for products packaging such as tapes, paper rolls and cylindrical products.

2. This machine can be connected with tape production line, collate and pack tapes in tower or in flat automatically.

3. Sealer made of alloyed material, coated with anti-stick telfon supported by four columns is very durable and repliable, makes a good sealing and reduces power consumption.

4. Adopt siemens plc and colorful touch screen, omron temperature controller, timer, relay, switch, and sensor.

5. The compact machine structure and super high efficiency can save more space for users.

Model	SK-075C
Sealing type	sleeve sealing
Power supply	380V/50-60Hz/3phase
Max product size	380(L) x 200(W) x 200(H)mm
Packing capacity	8-18 packs per minute
Film type	polyethylene (PE) film
Max film size	500(width) x 280mm(outer diameter)
Power consumption	max. 12kw
Tunnel oven size	entrance 1250(L) x 520(w) x 220(H)mm
Tunnel conveyor speed	variable, 40m/min
Tunnel conveyor	chains with silicon coated rods
Working height	850-900mm
Air pressure	≤0.5MPa(5 bar)
Sealing system	Special durable alloyed sealing knife with anti-stick Teflon coats
Operating panel	Siemens colorful touch screen, PLC, omron temperature controller
Machine material	carbon steel
Weight	700kg

Sleeve shrinking machine
